Multi-Mission & Multi-Functional
Shibli's radar solutions offer cutting-edge 2D and 3D capabilities for high-precision target detection and tracking across extended ranges with rapid refresh rates and multi-target handling. Once the radar detects and tracks a threat, it automatically cues electro-optical and infrared (EO/IR) sensors for precise identification, creating an integrated surveillance solution. Designed to provide real-time ground and aerial situational awareness, Shibli's radars counter threats posed to critical assets by humans, vehicles, tanks, and low-flying unmanned aerial systems, forming a powerful foundation for layered defense systems.
EXPLORE RADAR 2D/3D
Features
- Pulse Doppler AESA 2D and 3D Radars
- High efficacy in border/perimeter security solutions
- Advanced ECCM features
- State of the art signal processing algorithms
- Remarkable accuracies and resolutions
- Single and Multi Panel based deployment
- Highly scalable architecture due to modular design
SPECIFICATIONS
RADAR 2D/3D
MAIN FEATURES
Frequency
Instrumented Range
Elevation coverage
Azimuth coverage
No. of simultaneous tracks
Weight| Products | S-Band Radar | X-Band Radar | |
|---|---|---|---|
| Parameter | Instrumented Range (Km) | 60 | 50 |
| Range (RCS = 0.01 m²) (Km) | - | 8 | |
| Range (RCS = 0.1 m²) (Km) | 14 | 12 | |
| Range (RCS = 1 m²) (Km) | - | 20 | |
| Elevation Coverage (ft) | 30000 | - | |
| Range Accuracy (m) | 7.5 | - | |
| Range Resolution (m) | 30 | - | |
| Bearing Accuracy (deg) | 0.3 | - | |
| Bearing Resolution (deg) | 3 | - | |
| Height Accuracy (deg) | 0.3 | - | |
| Height Resolution (deg) | 1 | - | |
| Update Rate (secs) | 1 & 5 | 2 |
ACCESSORIES
Tripod Picatinny Interface
Std 1913 Picatinny Interface for mounting of Monoculars
Tripod
Universal interface tripod for use in mounted position for long observation
Solar Battery Charger
Foldable solar charger to charge AA Batteries / Power Bank
